GEL BATTERY 12V 200AH

Introducing the GEL Battery 12V 200AH, a reliable and efficient energy storage solution designed for optimal performance and longevity. Engineered with advanced technologies and high-quality materials, this battery is perfect for a wide range of applications, from renewable energy systems to backup power supplies.

Key Features:

• Longer Cycle Life: Featuring a special paste formula, over-dimensioned negative plate, and optimized manufacturing process with additives for deep discharge, this battery ensures an extended cycle life.
• Enhanced Internal Performance: Special separators are used to boost the battery’s internal performance, providing consistent and reliable energy output.
• Maintenance-Free Operation: Utilizing oxygen recombination technology, this battery requires no maintenance and has minimal water loss, ensuring hassle-free operation.
• Durable ABS Container: Made with ABS material, the battery container offers enhanced strength and durability. Flame-retardant ABS is also available as an option for added safety.
• Long Lifespan: Designed to have a lifespan of 12 years for float charging at 25°C, this battery provides a long-term energy storage solution.

Technical Specifications:

• Model: GEL Battery 12V 200AH
• Nominal Voltage: 12V
• Rated Capacity (10Hr rate): 200Ah
• Dimensions:
  • Length: 522mm (20.55″)
  • Width: 240mm (9.45″)
  • Height: 220mm (8.66″)
  • Total Height: 244mm (9.60″)
• Weight: Approximately 60.0kg ± 3%
• Capacity @25℃ (77℉):
  • 10 Hour (20A, 10.8V): 200Ah
  • 5 Hour (34A, 10.5V): 170Ah
  • 3 Hour (50A, 10.2V): 150Ah
  • 1 Hour (110A, 9.6V): 110Ah
• Internal Resistance: Fully charged at 25℃, approx. 6.0mΩ
• Max. Discharge Current: 2000A (5 Sec.)
• Capacity Affected by Temperature:
  • 40℃ (104℉): 102%
  • 25℃ (77℉): 100%
  • 0℃ (32℉): 85%
  • -15℃ (5℉): 65%
• Self Discharge Rate @25℃ (77℉):
  • After 3 months storage: 91%
  • After 6 months storage: 82%
  • After 12 months storage: 64%
• Charge Method:
  • Cycle Use: 14.1-14.4V (Initial current less than 73A) @25℃（77℉)
  • Float Charging: 13.5-13.8V @25℃（77℉)

The GEL Battery 12V 200AH is an excellent choice for those seeking a robust, maintenance-free battery with a long lifespan.
